Tait TP9400 Manual

TN-2817c-AN www.taitradio.com Page 3 of 14
1.1 Hardware Requirements
The following hardware is required to do this testing:
• 2 x Tait TP9300, TP9400, TP9500, TP9600 and/or TP3350 with suitable batteries and antennas
• Candidate Bluetooth® device under test
• 1x wired PTT (optional)
• 1x Tait Programming Cable to program the portable radios via a PC
1.2 Software Requirements
The following software is required for the following portable radio models:
• TP9300 – firmware v2.20.04 or later
• TP9400 – firmware v2.14.03 or later
• TP9500 – firmware v2.25.00 or later
• TP9600 – firmware v2.17.00or later
• TP3350 – firmware v1.04.00 or later
Refer to the Bluetooth® Functionality document TD-0016-xx for more details.
1.3 License Requirements
TPAS082 (SFE key - Bluetooth) must be enabled on the Tait TP9000 portable radios.
1.4 Radio Configurations
Two radio databases will be needed, one for each radio defined in this testing as “Radio A” and “Radio B”.
In addition to the normal configurations specific to your test setup e.g., Conventional Channel Profile; the
following specific settings are required to enable Bluetooth® functionalities on the radios.
1.4.1 TP9300/9400/9500/9600
On Radio A only:
• Global > PTT > Programmable/Bluetooth® PTT or VOX > Advanced > Audio Source as
‘Bluetooth® Mic’
• Function Key 2 (F2) Primary Action as ‘Programmable PTT’
• Function Key 4 (F4) Primary Action as ‘Bluetooth Devices Connect’
• Function Key 4 (F4) Long Press as “Bluetooth Devices Disconnect”
• Conventional > Conventional Menu > Bluetooth items enabled
On Radio B only:

Tait TP9400 Specifications

General

Battery Type	Li-Ion
Digital Protocol	DMR Tier II
Channel Spacing	12.5 kHz, 25 kHz
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Operating Voltage	7.4 V
Channels	1000
