TN-2817c-AN www.taitradio.com Page 5 of 14
1.5 Test Suite
1.5.1 Device Pair and Connect
Purpose: Evaluate the functionality and reliability of pairing and connecting the Bluetooth®
device under test with Tait portable radio.
Pair Single Device
TP9300/9400/9500/9600
1. Power-on both Radio A and Radio B.
2. Put an unpaired Bluetooth® Device into pair mode (as per manufacturer’s instructions)
with Radio A.
3. Press F4 on Radio A.
4. Follow the radio UI prompts until the device is connected.
5. Press and Hold F2 Programmable PTT (or the wired EPTT1 depending on configuration)
and verify Radio A transmitted audio is received on Radio B.
Release the F2 Programmable PTT and verify Radio B stops receiving audio.
TP3350
1. Power-on both Radio A and Radio B.
2. Put an unpaired Bluetooth® device into pair mode (as per manufacturer’s instructions).
3. On Radio A, search devices (Menu > Accessories > Bluetooth > My devices > Search
devices).
4. Follow the radio UI prompts until the device is connected.
5. Press and Hold PTT and verify Radio A transmitted audio is received on Radio B.
Release PTT and verify Radio B stops receiving audio.
Pair Multiple Devices
Purpose: Ease of changing between Bluetooth® devices under test with Tait portable radio.
TP9300/9400/9500/9600
1. Power-on all Bluetooth® devices and ensure that they are in paired mode (as per
manufacturer’s instructions).
2. Press F4 on Radio B.
3. Follow the radio UI prompts until one device is connected.
4. Long press F4 to disconnect the device.
5. Navigate to ‘Bluetooth’ and select ‘Find new devices’.

Tait TP9400 Specifications

General

Battery Type	Li-Ion
Digital Protocol	DMR Tier II
Channel Spacing	12.5 kHz, 25 kHz
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Operating Voltage	7.4 V
Channels	1000
