T2200P Weighing Indicator User’s Guide
- 2 -
SECTION 2 SPECIFICATIONS
Model T2200P
Resolution 1/15,000
Interface RS-232 Output Optional
Stabilisation Time 1 Seconds typical
Operating Temperature 0°C - 40°C / 32°F - 104°F
Power supply (external) 110/ 240 Vac, 50/60Hz
Calibration Automatic External
Display 6 digits 24mm LCD display, with LED backlight
indicator Housing ABS Plastic
Zero range 0mV~5mV
Signal input range 0~15mV
ADC Sigma delta
Internal counts 600,000
ADC update Max 60 times /second
Load cell drive voltage Max 5V/150mA
Load cells Up to four 350 ohms cells
Dimensions 280*160*170
