SPECIFICATIONS
<TB285/TB290>
Mono boom
OPERATING RANGES
*: With an angle dozer blade
Unit: mm (inch)
Item
Standard arm Middle arm Long arm
Rubber crawlers
A Maximum reach 7105 (279.6) 7275 (286.3) 7435 (292.7)
B
Maximum reach at ground reference
plane
6950 (273.6) 7125 (280.5) 7290 (287.0)
C Maximum digging depth 4220 (166.1) 4400 (173.2) 4570 (179.9)
D Maximum vertical digging depth 3455 (136.1) 3635 (143.1) 3805 (149.9)
E
Reach at maximum vertical digging
depth
4685 (184.4) 4720 (185.8) 4755 (187.1)
F Maximum height of cutting edge 7045 (277.3) 7175 (282.5) 7305 (287.5)
G Maximum dumping height 5010 (197.2) 5140 (202.4) 5270 (207.4)
H Minimum dumping height 1960 (77.2) 1795 (70.7) 1650 (65.0)
J Dozer blade maximum lifting 520 (20.4)
K Dozer blade maximum lowering 490 (19.3)
