7-11
SPECIFICATIONS
OPERATING RANGES
<TB285/TB290>
2-Piece boon
Unit: mm (inch)
Item Rubber crawlers
A Maximum reach 7700 (303.1)
B Maximum reach at ground reference plane 7560 (297.6)
C Maximum digging depth 4445 (175)
D Maximum vertical digging depth 4015 (158.1)
E Reach at maximum vertical digging depth 4045 (159.3)
F Maximum height of cutting edge 7980 (314.2)
G Maximum dumping height 6005 (236.4)
H Minimum dumping height 2310 (90.9)
J Dozer blade maximum lifting 520 (20.4)
K Dozer blade maximum lowering 490 (19.3)
*:
With an angle dozer blade
