2-68
CONTROLS
ACCESSORIES
Third auxiliary hydraulic warning lamp
This lamp illuminates and an alarm sounds
when the third auxiliary hydraulic pressure
drops abnormally, when the safety lock lever
is fully lowered to the unlocked position while
the engine is running.
Auxiliary 2/4 select button (If equipped)
This button is used to switch the operation
between the second auxiliary and the fourth
auxiliary.
Pressing this button while the second
auxiliary symbol is displayed on the LCD will
switch to the fourth auxiliary operation.
Pressing this button one more time will
display the second auxiliary symbol on the
LCD to indicate that the second auxiliary
operation is resumed.
The actual operation is performed with the
2nd/4th auxiliary switch (slider switch).
Refer to “Auxiliary 2nd/4th switch (if
equipped)” on page 2-36.
