5-61
MAINTENANCE
REPLACING THE AIR BREATHER FILTER
• Stop the engine and allow each part of
the machine to cool down before
performing maintenance.
· The engine, the hydraulic system and
many other parts of the machine are
hot immediately after the engine is
stopped. Touching these parts will
cause burns.
• Before performing maintenance on top
of the work bench, clean the footing and
observe the following precautions to
prevent falling.
· Do not spill oil or grease.
· Do not leave tools scattered around.
· Watch your step when walking.
• Never jump down from the machine or
the work bench. When getting on or off
the machine or work bench, use the
steps, handrails or work bench to
support your body. Your weight should
be evenly distributed among the three
contact points (one hand and two feet
or two hands and one foot).
• Do not stand on the dozer blade and
perform maintenance work. Doing so is
dangerous because of the unsteady
foothold. Use the work bench.
• Oil may spurt out if caps or filters are
removed or pipes are disconnected
before releasing the pressure in the
hydraulic system.
· Press the air breather button to relieve
the tank pressure.
EVERY 1000 HOURS
INSPECTING AND ADJUSTING THE
ENGINE VALVE CLEARANCE
This operation requires experience. Ask your
sales or service dealer for it.
INSPECTING THE ENGINE
COMPRESSION PRESSURE
This operation requires experience. Ask your
sales or service dealer for it.
INSPECTING AND CLEANING THE
ENGINE STARTER AND THE ALTERNATOR
This operation requires experience. Ask your
sales or service dealer for it.
1. Open the right side cover.
2. Press the button (K) to relieve the internal
pressure from the tank.
3. Remove the nut (N) on the air breather.
4. Remove the cover (H).
5. Replace the filter (A).
6. Install the cover (H) on the body (B).
7. Install the nut (N).
To Next Page
