Takeuchi TB295W User Manual

7-2
SPECIFICATIONS
BASIC SPECIFICATIONS
Type 2-Piece boom
MASS
Operating mass kg (lb)
Machines with an Outrigger 10195 (22475)
Equipped with a rear blade 9905 (21835)
Maximum operating mass** kg (lb) 10800 (23810)
PERFORMANCE
Bucket capacity
(Standard bucket)
m
3
(cu. ft.)
Heaped 0.245 (8.65)
Struck 0.185 (6.53)
Slew speed min
-1
(rpm) 10.3 (10.3)
Travel speed km/h (mph)
Forward
Creep 0 to 5.1 (3.17)
Low-speed travel 0 to 9.8 (6.09)
High-speed travel
0 to 29.2 (18.14)
/ 0 to 19.6 (12.18)*
Reverse
Creep 0 to 5.1 (3.17)
Low-speed travel 0 to 9.8 (6.09)
High-speed travel
0 to 29.2 (18.14)
/ 0 to 19.6 (12.18)*
Gradeability (degrees)
30
Noise level dB (A)
Sound power level LWA 99
Emission sound pressure level at the
operator’s position (ISO 6396,2008:)
L
pA 77
ENGINE
Manufacturer and model ISUZU 4JJ1X
Rated output
Net (ISO 14396) kW/min
-1
(hp/rpm) 77 / 2000 (103.3 / 2000)
Net (ISO 9249/
SAEJ1349)
kW/min
-1
(hp/rpm) 70.6 / 2000 (94.7 / 2000)
Displacement ml (cu.in.) 2999 (183)
Starter V-kW 24 - 4.0
Alternator V-kW 24 - 1.2
Battery (IEC 60095-1) V-A·h 12 - 90 X 2
BASIC SPECIFICATIONS
* : for Germany
** : This value is the maximum safe mass for operation specified by the manufacturer. Optional
accessories can be added until the operating mass exceeds this value.
