8-4
OPTIONS
ATTACHMENT COMBINATION TABLE
The table below shows which bucket should be installed when the machine is using a
standard arm (long arm). Select a proper bucket by following the table.
• Consult with Takeuchi before installing an optional attachment.
• Do not use any attachments not approved by Takeuchi. Doing so may cause safety
problems. Or, it may adversely affect the machine’s operation or service life.
• We will not be held responsible for any injuries, accidents or damage to its products
caused by the use by a non-approved attachment.
• The swing stopper must be installed when a bucket wider than a 750W (standard)
bucket is installed. Failure to do so may result in the bucket hitting the machine body.
√ :Can be used.
∆ :Can be used only for light operations (digging and loading of dry and loose soil or mud)
— :Cannot be used.
Total bucket mass = Bucket mass + Heaped bucket load (specific gravity: 1.8)
ATTACHMENT COMBINATION TABLE
Bucket
Rated capacity
m
3
(cu.yd.)
Bucket cutting width
mm (inch)
Long arm
2130 mm (84 in.)
430W
(no side cutter)
0.14 (0.18) 430 (16.9) √
500 W 0.14 (0.18) 500 (19.7) √
650 W 0.20 (0.26) 650 (25.6) √
750 W (S.T
.D.) 0.25 (0.33) 750 (29.5) √
Total bucket weight=
Within 657 kg (1448 lb.)
W
ithin
750 (29.5)
√
Hydraulic Breaker (TKB-401) —
To Next Page
