Takeuchi TB295W User Manual

7-7
SPECIFICATIONS
MACHINE DIMENSIONS (MACHINES WITH AN OUTRIGGER)
Unit: mm (inch)
Item 2-Piece boom Mono-boom
A Overall length 6815 (268.2) 6320 (248.8)
A’ Overall length (Road travel posture) 4925 (193.8) 5605 (220.7)
B Overall width 2335 (91.9)
C Overall height 2925 (115.1) 3265 (128.5)
C’ Overall height (Road travel posture) 4000 (157.4) 3990 (157.0)
D Slew radius 1690 (66.5)
E Clearance height under upperstructure 1140 (44.8)
F Wheel base 2200 (86.6)
G Tread 1810 (71.3)
H Overall length of undercarriage 4165 (163.9)
J Overall height of base machine 2930 (115.3)
K Ground clearance of undercarriage 320 (12.5)
L Front distance to axis of rotation 4835 (190.4) 4340 (170.9)
M Rear distance to axis of rotation 1980 (77.9)
N Dozer blade width 2300 (90.6)
P Dozer blade height 500 (19.7)
Q Swing angle of axles 7.5°
R Minimum turning radius (Tire) 5490 (216.2)
S Minimum turning radius (Dozer blade) 6020 (237.0)
T Outside machine clearance radius 5765 (227.0) 6255 (246.3)
V Minimum turn radius (outrigger) 5195 (204.5)
W Overall width of upperstructure 2235 (88.0)
X
Minimum radius of equipment at maximum
front offset (Right)
2190 (86.3) 2260 (89.0)
Y
Minimum radius of equipment and
attachment
2675 (105.4) 2755 (108.4)
Z
Minimum radius of equipment at maximum
front offset (Left)
2495 (98.1) 2565 (101.1)
a Offset distance of bucket (Left) 685 (27.1)
b Offset distance of bucket (Right) 890 (35.1)
c Boom swing angle (Right) 60°
d Boom swing angle (Left) 70°
