7-9
SPECIFICATIONS
Unit: mm (inch)
Item 2-Piece boom Mono-boom
A Maximum reach 7730 (304.3) 6830 (268.8)
B Maximum reach at ground reference plane 7505 (295.6) 6570 (258.7)
C Maximum digging depth 4115 (162) 3895 (153.4)
D Maximum vertical digging depth 3625 (142.7) 3080 (121.2)
E Reach at maximum vertical digging depth 4385 (172.7) 4215 (165.9)
F Maximum height of cutting edge 8400 (330.8) 6630 (260.9)
G Maximum dumping height 6475 (254.9) 4615 (181.8)
H Minimum dumping height 2905(114.4) 1225 (48.2)
J Dozer blade maximum lifting height 400(15.7)
K Dozer blade maximum lowering depth 150 (5.9)
L Outrigger maximum lowering depth 150 (5.9)
OPERATING RANGES
