Talsa H15 - Standard & Optional Accessories; Model Designations; Possible Configurations

H PISTON FILLERS/STUFFERS
MANUAL
EN-20
2.1 Standard & Optional Accessories
Standard accessories included:
Optional accessories available through your authorized dealer:
 Three nozzles ø12, 20, 30 mm.
 Spanner
 Piston extraction screw.
 Spare lid gasket.
 Nozzle holding nut.
 Hydraulic oil.
 Oil cap/dipstick.
 Instruction manual.
Contact your authorized dealer for
spare parts!
 Stainless steel lid, piston and nut (standard on the H26S & H31S models).
 Single-phase motor.
 Portioning device PH500.
 Curved nozzle valve.
 The following special diameter or length nozzles:
Model
B
C
D
E
F
G
H
I
External diameter, mm Ø
12
15
18
20
25
30
38
43
Internal diameter, mm Ø
10
12
15
17
22
27
35
40
Tube length, mm
160
195
195
195
195
195
220
235
Total nozzle length, mm
210
245
245
233
220
220
245
260
2.2 Model Designations
The digits and letters that make up a particular model’s designation have significance. Here’s what they mean:
H
=
Works by means of a high pressure hydraulic system.
2 dígitos
=
These numbers indicate the dough barrel’s capacity in liters.
p
=
Equipped with a robust, rectified fixed barrel.
i
=
The motor is turned on & off by means of a manual switch.
a
=
The motor starts & stops automatically via contactor and microswitch when the knee lever is used.
s
=
The lid, piston and nut are made of stainless steel.
m
=
Indicates a single phase machine.
2.3 Possible Configurations
Model
Characteristics y options
p – fixed barrel
i – manual switch
a - automatic
s – stainless steel
m – single phase
H15
Standard
Standard
Optional
Not Available
Optional
H20
Standard
Standard
Optional
Not Available
Optional
H26
Standard
Standard
Optional
Optional
Optional
H31
Standard
Standard
Optional
Optional
Optional
H42
Standard
Not Available
Standard
Standard
Optional
H52
Standard
Not Available
Standard
Standard
Optional
