5. SPARE PARTS
IOM manual Tapflo Metal Series 34
5.1.5. TX70-TX420 – Spare parts - Options
Twin connection - TT
130
2
Twin in/outlet
Aluminium, CI
Drum pump - TD
63
1
Drum pump inlet
Aluminium, CI
64
1
Pump tube
Aluminium
65
1
Handle
AISI 316L
17
4
Rubber foot
NBR
172
4
Washer
A4-70
171
4
Domed nut
A4-70
Diaphragm stroke sensor – 5C
121
1
Centerblock for stroke
sensor
Aluminium,
CI
74
1
Inductive sensor
CuZn
76
1
Sensing plate
AISI 316L
Diaphragm stroke sensor – 5C
116
2
Pump housing for ball
lifter
Aluminium
95
4
Ball lifter
AISI 316L
Optional connections – 3…
70
2
Flange pipe (thread)
AISI 316L
71
2
ANSI flange ring
AISI 316L
73
2
DIN flange ring
AISI 316L
712
2
JIS flange ring
AISI 316L
721
2
Integrated manifold
with loose flange
AISI 316L
7000
2
Male camlock
Aluminium
179
4
Pump feet
AISI 316L
1791
4
Pump feet screw
A4-70
1792
4
Pump feet washer
A4-80
External air supply – 5EC
124
1
Centerblock
Aluminium, CI
