6.3. Technical data
TECHNICAL DATA
PUMP SIZE
TX25 A/C
TX70 A/C
TX120 A/C
TX220 A/C
TX420 A/C
TX820 A
Max capacity* [l/min] / [US GPM]
26 / 6.8
78 / 20
158 / 41
330 / 87
570 / 150
820 / 216
Volume per stroke** [ml] / [cu in]
45 / 2.75
105 / 6.4
272 / 16.2
884 / 54
2440 / 149
4897 / 299
Max discharge pressure [bar] / [psi]
8 / 116
8 / 116
8 / 116
8 / 116
8 / 116
8 / 116
Max air pressure [bar] / [psi]
8 / 116
8 / 116
8 / 116
8 / 116
8 / 116
8 / 116
Max suction lift dry [m] / [Ft]
1.5 / 5
3 / 9.8
4 / 13
4 / 13
4 / 13
4 / 13
Max suction lift wet [m] / [Ft]
8 / 26
8 / 26
8 / 26
8 / 26
8 / 26
8 / 26
Max size of solids ø in [mm] / [in]
3 / 0.12
4 / 0.16
6 / 0.24
10 / 0.39
15 / 0.59
13 / 0.51
Max temp. pump with EPDM [°C] / [°F]
90 / 194
90 / 194
90 / 194
90 / 194
90 / 194
90 / 194
Max temp. pump with NBR [°C] / [°F]
70 / 158
70 / 158
70 / 158
70 / 158
70 / 158
70 / 158
Max temp. pump with PTFE [°C] / [°F]
110 / 230
110 / 230
110 / 230
110 / 230
110 / 230
110 / 230
Weight of pump in aluminium [kg] / [lb]
2 / 4.4
5 / 11
8.65 / 19.1
18.1 / 39.9
36.8 / 81.1
101.5 /
223.8
Weight of pump in cast iron [kg] / [lb]
4.1 / 9
9.9 / 21.8
17.6 / 38.8
33.4 / 73.6
71.4 / 157.4
-
Connection standard in aluminium and
cast iron pumps
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
Connection standard in stainless steel
pumps
-
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
DIN 2642
flange
TECHNICAL DATA
PUMP SIZE
T70 S
T120 S
T220 S
T420 S
T820 S
Max capacity* [l/min] / [US GPM]
78 / 20
158 / 41
330 / 87
570 / 150
820 / 216
Volume per stroke** [ml] / [cu in]
101 / 6.2
304 / 18.5
962 / 58.7
2480 / 151.3
3452 / 210.7
Max discharge pressure [bar] / [psi]
8 / 116
8 / 116
8 / 116
8 / 116
8 / 116
Max air pressure [bar] / [psi]
8 / 116
8 / 116
8 / 116
8 / 116
8 / 116
Max suction lift dry [m] / [Ft]
3 / 9.8
4 / 13
4 / 13
4 / 13
4 / 13
Max suction lift wet [m] / [Ft]
8 / 26
8 / 26
8 / 26
8 / 26
8 / 26
Max size of solids ø in [mm] / [in]
4 / 0.16
6 / 0.24
10 / 0.39
15 / 0.59
13 / 0.51
Max temp. pump with EPDM [°C] / [°F]
90 / 194
90 / 194
90 / 194
90 / 194
90 / 194
Max temp. pump with NBR [°C] / [°F]
70 / 158
70 / 158
70 / 158
70 / 158
70 / 158
Max temp. pump with PTFE [°C] / [°F]
110 / 230
110 / 230
110 / 230
110 / 230
110 / 230
Weight of pump in AISI 316L [kg] / [lb]
6.8 / 15
15.5 / 34.2
35.9 / 79.2
66.1 / 145.7
137 / 302
Connection standard in aluminium and
cast iron pumps
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
Connection standard in stainless steel
pumps
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
BSP female
thread (G)
DIN 2642
flange
* = Recommended flow is half of the max flow, i.e. recommended flow for a T70 is 39 l/min
** = Based on pumps with PTFE diaphragms. Using rubber diaphragms will increase the volume per stroke.
