6. DATA
IOM manual Tapflo Metal Series 50
6.4. Dimensions
Dimensions in mm (where other is not indicated)
Dimensions in inch (where other is not indicated)
General dimensions only, ask us for detailed drawings. Changes reserved without notice.
Dim
PUMP SIZE
T25
T70
T120
T220
T420
T820 A
T820 S
A
105
150
200
275
356
470
760
4.13
5.91
7.87
10.83
14.02
18.50
29.92
B
117
167
198
267
342
488
-
4.61
6.57
7.80
10.51
13.46
19.21
-
B2
-
157
200
282
347
-
750
-
6.18
7.87
11.10
13.66
-
29.53
D
162
233
302
419
539
840
-
6.38
9.17
11.89
16.50
21.22
33.07
-
D2
173
249
322
-
-
-
-
6.81
9.80
12.68
-
-
-
-
D3
-
229
310
422
529
-
1341
-
9.02
12.20
16.61
20.83
-
52,80
E
132
190
252
346
448
688
-
5.20
7.48
9.92
13.62
17.64
27.09
-
E2
147
216
279
-
-
-
-
5.79
8.50
10.98
-
-
-
-
E3
-
192
257
348
443
-
1035
-
7.56
10.12
13.70
17.44
-
40.75
F
13
20
20
-
-
-
-
0.51
0.79
0.79
-
-
-
-
G
11
18
20
26
38
50
-
0.43
0.71
0.79
1.02
1.50
1.97
-
G2
-
17
20
31
36
-
25
-
0.67
0.79
1.22
1.42
-
0.98
H
12
19
20
29
30
53
-
0.47
0.75
0.79
1.14
1.18
2.09
-
H2
-
13.5
23.5
34
32
-
13
-
0.53
0.93
1.34
1.26
-
0.51
I
16
22
27
34
47
82
-
0.63
0.87
1.06
1.34
1.85
3.22
-
I2
-
19
27
38
44
-
206
-
0.75
1.06
1.50
1.73
-
8.11
J
½”
3/4”
1”
1 ½”
2”
3”
DN80 (3”)
½
3/4
1
1 ½
2
3
DN80 (3”)
J2
3/8”
½”
3/4”
1”
2”
-
-
3/8
½
3/4
1
2
-
-
ØK
6.5
10
10
10
10
12.5
25x13
0.26
0.39
0.39
0.39
0.39
0.49
1x0.5
L
1/8”
¼”
¼”
½”
½”
3/4”
3/4”
1/8
¼
¼
½
½
3/4
3/4
M
19
29
33
45
57
84.5
-
0.75
1.14
1.30
1.77
2.24
3.33
-
M2
-
40
52
70
90
-
126
-
1.57
2.05
2.76
3.54
-
4.96
N
82
117
153
207
274
356
-
3.23
4.61
6.02
8.15
10.79
14.02
-
N2
-
115
155
212
266
-
724
-
4.53
6.10
8.35
10.47
-
28.50
P
30
47
39
59
59
72.5
-
1.18
1.85
1.54
2.32
2.32
2.85
-
P2
-
82
105
143
183
-
238
-
3.23
4.13
5.63
7.20
-
9,37
R
-
15°
15°
0°
0°
-
0°
-
15°
15°
0°
0°
-
0°
S
12.5
21
26
35
40
-
-
0.49
0.83
1.02
1.38
1.57
-
-
ØT
20
30
30
-
-
-
-
0.79
1.18
1.18
-
-
-
-
U
1170
1170
1170
-
-
-
-
46.06
46.06
46.06
-
-
-
-
V
286
374
400
-
-
-
-
11.26
14.72
15.57
-
-
-
-
