TapFlo TX70 - Pump with Integrated Pulsation Dampener - TXK

4. OPTIONS
IOM manual Tapflo Metal Series 30
4.6. Pump with integrated pulsation dampener – TXK…
The TK pump is a compact and ready to use integrated
set of a Tapflo AOOD pump and DT pulsation dampener.
This allows to obtain optimal pulsation dampening
effect while minimizing space needed for pulsation
dampener installation. All aluminium AODD pumps with
integrated pulsation dampener are ATEX rated.
Available only in aluminium version for pump sizes:
• TX25, TX70, TX120, TX220 and TX420
Art. no
Q-ty
Description
Material
6-xx1-112
1
Dampener housing/ pump
outlet
Aluminium
6-xx1-12
1
Dampener centre body
Aluminium
6-xx0-15
1
Dampener diaphragm
EPDM*, PTFE, NBR*, PTFE
1705b
6-xx0-37
12
Dampener nut
A4-70
6-xx0-38
12
Dampener washer
A4-70
6-xx0-36
5
Dampener PE seal
PE
6-xx0-47
5*/10*
*
Dampener O-ring
NBR, EPDM, FKM
6-xx1-16
1
Dampener shaft
AISI 316L
6-xx1-14
6
Dampener pinscrew
A4-80
6-xx1-25
1
Dampener muffler
PPM-F
