5.1.7. TX820 – Spare parts list
Pos.
Q-ty
Description
Material
KIT
LIQ
KIT
AIR
11
2
Housing
AK9 aluminium, PTFE coated aluminium
12
1
Centre block
AK9 aluminium, PTFE coated aluminium
13
2
In/Outlet
AK9 aluminium, AISI 316L
15
2
Diaphragm
EPDM, PTFE, NBR
X
16
1
Diaphragm shaft set
AISI 316L
X
18
4
O-ring set (in/outlet)
Klingerseal/NBR (std), Klingerseal/EPDM, Klingerseal/FKM
X
X
22
4
Stopper assembly
AISI 316L; NBR, EPDM O-ring
23
4
Valve ball
EPDM, PTFE, PU, NBR
X
25
1
Muffler
PP
X
27
2
Circlip
Cr3 coated steel
30
6
O-ring
NBR (standard), EPDM, FKM
36
4
Center block seal
PE
X
37
16
Screw
Zinc plated steel / A4-70 *
38
16
Washer
Zinc plated steel / A4-70 *
47
4
O-ring (back-up 36)
NBR
X
61
1
Air valve complete
Body: PET; O-rings: NBR, FKM, EPDM
X
90
1
Grounding set
AISI 316L
* = Aluminium / PTFE coated pump
