Rear Panel
Do not touch the inner pins of the jacks on the rear panel. Electrostatic discharge may cause
permanent damage to the unit.
8
6
6
6
6
6
S-VIDEO OUT
MONITOR OUT
AUX IN
S-VIDEO OUT Connector
FM Antenna Connector
AM Loop Antenna Connectors
SPEAKER Connectors
POWER CORD
MONITOR OUT Connector
AUXILIARY INPUT Connectors
REMOTE CONTROL OPERATION RANGE
Point the remote control at the remote sensor and
press the buttons.
Distance: About 20 ft (6 m) from the front of the
remote sensor
Angle: About 30° in each direction in front of the
remote sensor
Attention!
Dispose worn-out batteries not with your domestic
waste.
Please contact your local government for disposal
prastics in your area.
REMOTE CONTROL BATTERY INSTALLATION
Remove the battery cover on the rear
of the remote control, and insert two
R03 (size AAA) batteries with and
aligned correctly.
Caution
Do not mix old and new batteries. Never mix different
types of batteries (standard, alkaline, etc.).
Attention!
Only standby power.
This device has power consumption in standby mode.
