Target Windham - Kitchen Island Assembly Process; Step 1: Attach Lower Back Panel, Partition Panel and Slat Panel

7
step 1: attach lower back panel, partition panel and slat panel
(H1) x 4
wooden dowel
(H2) x 4
cam bolt
(H3) x 4
cam
1.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out.
1.2. Screw-In cam bolts must be screwed down ush.
1.3.
Refer to page 6 for instructions on how to use the cam lock system.
