TASCAM Model 16
14 - Specifications
General
Supported media
SD cards (Class 10 or more)
SDHC cards (Class 10 or more)
SDXC cards (Class 10 or more)
File System
SD card: FAT16
SDHC card: FAT32
SDXC card: exFAT
Recording file formats
WAV (BWF): 44.1/48kHz, 16/24-bit (Maximum file size: 2 GB)
Playback file formats
WAV (BWF): 44.1/48kHz, 16/24-bit
Recordable Channel
Max. 16 channels (14ch + 2 stereo mix)
Inputs and outputs
Analog audio input and output ratings
MIC input jacks (1-8, 9, 11)
Connectors: XLR-3-31 (1: GND, 2: HOT, 3: COLD)
Maximum input level: +10 dBu
Nominal input level: -8 dBu
Minimum input level: -58 dBu
Gain adjustment range: 0 - 50 dB
Input impedance: 1.8 kΩ
LINE/INST (BAL) input jacks (1-2)
Connectors: 6.3mm (1/4”) standard TRS jacks
(Tip: HOT, Ring: COLD, Sleeve: GND)
Maximum input level: +22 dBu
Nominal input level: +4 dBu
Gain adjustment range: -10 - +40 dB
Input impedance: 22 kΩ (LINE)/1 MΩ (INST)
LINE (BAL) input jacks (3-8)
Connectors: 6.3mm (1/4”) standard TRS jacks
(Tip: HOT, Ring: COLD, Sleeve: GND)
Maximum input level: +22 dBu
Nominal input level: +4 dBu
Gain adjustment range: -10 - +40 dB
Input impedance: 22 kΩ
L/MONO (BAL) / R (BAL) input jacks
(
9/10-11/12)
Connectors: 6.3mm (1/4”) standard TRS jacks
(Tip: HOT, Ring: COLD, Sleeve: GND)
Maximum input level: +22 dBu
Nominal input level: +4 dBu
Gain adjustment range: -20 - +30 dB
Input impedance:
18 kΩ
INSERT jacks (1-2)
Connectors: 6.3mm (1/4”) standard TRS jacks
(Tip: SEND, Ring: RETURN, Sleeve: GND)
RETURN (Ring)
Nominal input level: 0 dBu
Maximum input level: +18 dBu
Input impedance: 10 kΩ
SEND (Tip)
Nominal output level: 0 dBu
Maximum output level: +18 dBu
Output impedance: 100 Ω
−10dBV input jacks (13/14)
Connectors: RCA pin jacks
Maximum input level: +8 dBV
Nominal input level: -10 dBV
Input impedance: 10 kΩ
STEREO input jack (13/14)
Connector: 3.5mm stereo mini jack
Maximum input level: +8 dBV
Nominal input level: -10 dBV
Input impedance: 10 kΩ
MAIN OUTPUT L/R jacks
Connectors: XLR-3-32 (1: GND, 2: HOT, 3: COLD)
Nominal output level: +4 dBu
Maximum output level: +22 dBu
Output impedance:
200 Ω
SUB OUTPUT L/R jacks
Connectors: 6.3mm (1/4”) standard TRS jacks
(Tip: HOT, Ring: COLD, Sleeve: GND)
Nominal output level: -2 dBu
Maximum output level: +16 dBu
Output impedance:
200 Ω
AUX OUTPUT MON 1/2 jacks
Connectors: 6.3mm (1/4”) standard TRS jacks
(Tip: HOT, Ring: COLD, Sleeve: GND)
Nominal output level: -2 dBu
Maximum output level: +16 dBu
Output impedance:
200 Ω
AUX OUTPUT FX jack
Connector: 6.3mm (1/4”) standard TRS jack
(Tip: HOT, Ring: COLD, Sleeve: GND)
Nominal output level: -2 dBu
Maximum output level: +16 dBu
Output impedance:
200 Ω
CONTROL ROOM L/R jacks
Connectors: 6.3mm (1/4”) standard TRS jacks
(Tip: HOT, Ring: COLD, Sleeve: GND)
Rated output level: -2 dBu
Maximum output level: +16 dBu
Output impedance:
200 Ω
PHONES jack
Connector: 6.3mm (1/4”) standard stereo jack
Maximum output: 80mW + 80mW (32Ω load)
