Format: AES3-2003 (AES/EBU)
DIGITAL OUTPUT L-R
Connector: XLR-3-32
Output voltage: 2–5 Vp-p/110 Ω
Format: AES3-2003 (AES/EBU)
Control input and output connectors
RS-422
Connector: D-sub9-pin
RS-232C
Connector: D-sub9-pin
PARALLEL
Connector: D-sub25-pin
CASCADE IN
Connector: BNC
Input voltage: 5V TTL equivalent
Input impedance: 75Ω ±10% Allowable frequency
deviation of external synchronization: ± 100 ppm
CASCADE OUT
Connector: BNC
Output voltage: 5V TTL equivalent
Output impedance: 75Ω ±10%
Sampling frequency: 44.1/47.952/48/48.048/88.2/96/
176.4/192 kHz (47.952/48.048 kHz: 48 kHz 0.1% pull
down/0.1% pull up)
TIME CODE IN
Connector: BNC
Input voltage: 0.5 - 5 Vp-p
Input impedance: 20 kΩ
TIME CODE OUT
Connector: BNC
Output voltage: 2 Vp-p
Output impedance: 600Ω
WORD/VIDEO IN
Connector: BNC
Input voltage: 5V TTL equivalent
Input impedance: 75Ω ±10%
Allowable frequency deviation of external
synchronization: ± 100 ppm
Includes switch for enabling termination
WORD/VIDEO THRU/OUT
Connector: BNC
Output voltage: 5V TTL equivalent
Output impedance: 75 Ω ±10%
Sampling frequency (when using WORD): 44.1/47.952
/48/48.048/88.2/96/176.4/192 kHz (47.952/48.048:
48 kHz ± 0.1% pull-down/pull-up)
OUT/THRU switch included (OUT is only for WORD
OUT)
ETHERNET
Connector: RJ45
Keyboard
Connector: Mini-DIN (PS/2)
USB
Connector: USB A-type 4-pin
Protocol: USB2.0 HIGH SPEED (480 Mbps)
Audio performance
Frequency response
ANALOG INPUT → ANALOG OUTPUT:
20 Hz - 20 kHz ±0.5 dB (Fs = ALL)
at 40 kHz +0.5 dB/–2 dB (Fs = 88.2/96 kHz)
at 80 kHz +0.5 dB/–5 dB (Fs = 176.4/192 kHz)
Distortion
ANALOG INPUT ∑ ANALOG OUTPUT: 0.005% or less
(Reference level: When –20 dB, +23 dBu input, 1
kHz, AES-17LPF)
S/N ratio
ANALOG INPUT ∑ ANALOG OUTPUT: 100 dB or more
(22 kHz LPF A-weighted)
Other specifications
Power
AC 100-240 V, 50-60 Hz
Power consumption
26 W
External dimensions (W x H x D)
482.7 x 88 x 284.4 mm/
19 x 3.465 x 11.2 in.
Weight
4.8 kg/10.58 lb
Operating temperature range
5–35ºC/41–95ºF
13 – Specifications
