4 - Buss functions
TASCAM TM-D1000 Operations Manual
12
4.5 Where do the busses go?
As you can see from the above description, the L-R
stereo buss is not used for recording in the REC
modes. It goes straight out to the
STEREO outputs
(analog or digital) and to the
MONITOR buss (paral-
leled to the headphone output). You should therefore
use it as a monitor or cue buss when recording.
The behavior of the group outputs depends on the
number of group outputs which are being used in the
currently-selected buss function.
Groups are always routed through to the TDIF-1 out-
put connector; the exact routing pattern is described
here.
• If both sets of groups (1-2 and 3-4) are in use, these
are assigned to the TDIF-1 output busses with the
same numbers, and are also “doubled” to 5-6 and
7-8 respectively.
• If only one set of groups is in use, it is always
group 3-4. This pair of groups is routed to all
TDIF-1 output busses, with four “copies” of this
pair going to 1-2, 3-4, 5-6, and 7-8.
These routing patterns are fixed, and cannot be
changed.
