Task Force Tips Ball Intake Valve Instructions For Safe Operation And Maintenance

8.0 DRAWINGS AND PARTS LISTS
Index Description QTY Part #
1 BGIV BODY - POWDER COAT 1 A1015
2 O-RING-236 3-1/4 ID 1/8 C/S 1 VO-236
3 BACK RING STAINLESS STEEL 1 A1201S
4 VALVE SEAT 1 A1520
5 PLASTIC STRIP 7.00" 1 A1290
6 SEAL RETAINER 1 A1521S
7 COUPLING 5.0"NHF X PSF7.0-NFS 1 A1261NT
COUPLING 6.0"NHF X PSF7.0-NFS 1 A1266NX
8 GASKET - 5.0" HOSE COUPLING 1 V3220
GASKET - 6.0" HOSE COUPLING 1 V3240
9 PORT PLUG 1 A1299
10 RETAINING RING 1 VR4275
11 SMALL BUSHING 1 A1525
13 GEAR BOX 1 A1505
14 3/8-16 X 1 1/4 SOCKET HEAD CAP SCREW 4 VT37-16SH1.2
15 5/32 X 7/8 HDP SPIROL PIN #12437 1 V1900
16 POSITION INDICATOR 1 A1517
17 LABEL; BGIV GEARBOX 1 AL010
18 BUTTON HEAD SCREW 2 VP25-20BH500
20 KNOB 1 A1512
21 WASHER .812 OD X .406 ID X .065 THICK 2 VW812X406-65
22 CRANK BUSHING 1 A1513
23 3/8-16 X 1.5 BUTTON HEAD CAP SCREW 1 VT37-16BH1.5
24 CRANK SHAFT 1 A1510
25 KEY, 1/8" X 1.00" 1 X225
27 THIN WASHER 2 A1530
28 12 DP WORM 1 X220
29 INTERNAL WORM GEAR TRUNNION 1 A1501
30 GEAR THRUST WASHER 1 A1502
31 GEAR SPACER 1 A1511
32 3/8-16 X 5/16 SOCKET SET SCREW CUP POINT P 2 VT37-16SS312
33 1/4" BALL - 302 STAINLESS STEEL 72 V2125
36 CUP SEAL 6.0” ID X 3/16 C/S 1 A1545
37 HALF BALL STAINLESS STEEL 1 A1043S
38 ELBOW 4" (4” STORZ ONLY) 1 A1071
ELBOW 5" 1 A1054
42 ½ BARB X ¼ NPT FITTING 1 XX329
43 DETENT PIN 1 A1560
44 SPRING 1 X345
45 DETENT PIN HOUSING 1 A1570
46 DETENT PIN KNOB 1 A1575
47 SPIROL PIN 1 VP125X750H
48 LOCKING LEVER - MOLDED 1 A4171
49 SPRING TORSION 1 A4230
SPOUT 4”NHM X PSF5.25 1 A4620N
SPOUT 4.5”NHM X PSF5.25 1 A4625N
SPOUT 5”NHM X PSF5.25 1 A4630N
COUPLING 4.0”NH X PSF5.25 1 A4660N
COUPLING 4.5”NH X PSF5.25 1 A4665N
COUPLING 5.0”NH X PSF5.25 1 A4670N
COUPLING 6.0”NH X PSF7.0 1
MATE PSF5.25 X PSM7.0 1
PLASTIC STRIP 5.25" 1
CUP SEAL 5.25 X 4.750 X ¼ 1
LABEL; PORT COVER 1
BALL 7/16" STAINLESS 1
COUPLING HEAD STORZ 4" X 4.25PSF 1
INSERT RING STORZ 4” 1
O-RING 155 4” ID X 3/32 C/S 1
50
A1266NX
A4745
A1291
A1596
A1298
VB.437
A4114
A4164
VO-155
COUPLING HEAD STORZ 5" X 5.25PSF 1 A4115
INSERT RING STORZ 5” 1 A4165
O-RING 250, 5” ID X 1/8 C/S 1 VO-250
Continued on Next Page
Ball Intake Valve Parts List
9
©Copyright Task Force Tips, Inc. 2002-2006
