Index Description QTY Part #
1 1/2-13 X 1.0 BUTTON HEAD CAP SCREW 1 VT50-13BH1.0
2 O-RING-236 3-1/4 ID 1/8 C/S 1 VO-236
3 DEBRIS WASHER 1 A1169
4 HOUSING W/OUT THDS 1 A1150
5 5/16-18 X 3/8 SOCKET SET SCREW CUP POINT 1 VT31-18SS375
6 VALVE SEAT 1 A1168
7 PISTON -HARDCOAT 1 A1160
8 O-RING-231 2-5/8 ID 1/8 C/S 1 VO-231
9 QUAD RING 422 1.5 ID X 1/8 C/S 2 VOQ-4222
11 SPRING SEAT 1 A1166
12 RELIEF SPRING 1 A1170
13 SMALLEY RING 1 V4210
14 ADJUSTING SCREW 1 A1167
15 SPRING HOUSING 1 A1164
16 COVER PLATE/CAP 1 X631
8.0 DRAWINGS AND PARTS LISTS
Index Description QTY Part #
COUPLING HEAD STORZ 6" X 5.25PSF 1
INSERT 6.0"BSPM X PSF5.25 1
COUPLING HNDL 4.0"NHF X PSF5.25 1
COUPLING HNDL 4.5”NHF X PSF5.25 1
COUPLING SH 5.0"NHF X PSF7.0 NFS 1
MATE PSF5.25 X PSM7.0-NFS 1
50 PLASTIC STRIP 5.25" 1
CUP SEAL 5.25 X 4.750 X ¼ 1
LABEL; PORT COVER 1
BALL 7/16" STAINLESS 1
*X696SX-LOCK
A4765
A4560N
A4565N
A1261NT
A4745
A1291
A1596
A1298
VB.437
COUPLING SH 6.0"NHF X PSF7.0-NFS 1 A1266NX
MATE PSF5.25 X PSM7.0-NFS 1 A4745
PLASTIC STRIP 5.25” 1 A1291
CUP SEAL 5.25 X 4.750 X ¼ 1 A1596
LABEL; PORT COVER 1 A1298
BALL 7/16" STAINLESS 1 VB.437
GASKET 4” PRESSURE (4” STORZ ONLY) 1 A4215
GASKET 4” PRESSURE (4” STORZ ONLY)/VACUUM 1 A4216
GASKET 5” PRESSURE (5” STORZ ONLY) 1 A4220
GASKET 5” PRESSURE (5” STORZ ONLY)/VACUUM 1 A4221
51 GASKET 6” PRESSURE (6” STORZ ONLY)/VACUUM 1 A4226
GASKET 4.0” HOSE COUPLING 1 V3198
GASKET 4.5” HOSE COUPLING 1 V3210
GASKET 5.0” HOSE COUPLING 1 V3220
GASKET 6.0” HOSE COUPLING 1 V3240
52 PLASTIC STRIP 4.25" (4” STORZ ONLY) 1 A1292
PLASTIC STRIP 5.25" 1 A1291
53 CUP SEAL 4.25X3.750 X 1/4 (4” STORZ ONLY) 1 A1597
CUP SEAL 5.25 X 4.750 X 1/4 1 A1596
54 BALL 7/16" STAINLESS 302 1 VB.437
56 HOLLOW TRUNNION 1 A1514
57 7/16-14 X 1 HEX HEAD BOLT 4 VT43-14HX1.0
58 LONG BUSHING 1 A1526
59 HANDWHEEL 1 X281
60 NAMEPLATE 1 A1306
61 DRAIN BODY 1 A1543
62 O-RING-115 2 VO-115
63 DRAIN SLEEVE 1 A1541
64 DRAIN LEVER 1 A1542
65 DOG POINT SCREW 1 H515
66 O-RING-110 1 VO-110
67 O-RING-128 1 VO-128
68 O-RING-214 1 VO-214
69 SET SCREW 1 VT31-18SS375
Relief Valve Parts List
10
