Taski swingo 755 - Structural Layout

88
Structural layout
1 Switch bracket drive
2 Driving handle
3 Operating hour counter (option)
4 Drain hose cleaning solution (blue cover)
5 Drain hose waste water (red cover)
6 Water regulating set
7 Foot pedal tool
8 Foot pedal squeegee
9 Squeegee
10 Tools (brushes, pads, etc.)
11 Brush unit
12 Cleaning solution switch
13 Suction unit switch
14 Main switch
15 Filling level indicator
16 Fresh water tank filter
17 Recovery tank
18 Float (Overfill protection recovery tank)
19 Suction filter
20 Dirt sieve
21 Solution tank
22 Dosage aid
23 Tank lid
24 Tank lid unlocking
8
910
7
6
2
3
4
5
1
14
13
12
11
21 2022
15
16
17
18
19
24
23
max.60°C
max.140°F
MAX
3/4
1/2
