tau D760M User Manual

3 D760M
SCHÉMA CÂBLAGE D760M / ESQUEMA DEL CABLEADO D760M / ESQUEMA ELÉCTRICO D760M
O/C =Open/Close
Ped = Pedestrian
Cap = Capacitor
TX = Transmitter
RX = Receiver
E.L. = Electric lock
M = Motor
SPIA
AP2
230Vac
M3
1
2
3 4 5 6 7 8 9 10
CH1 COM1 AP1 CH2 COM2
FOTI
11 12 13 14 15 16
COM AP/CH PED STOP CF
COM
17 18
FOTE
24FOT
25
0VAC
26 2722 23 2419 20 21
24VAC
LAMP
M2 M1
E.SERR
2 CH
230 Vac
Power supply
Flashing
light
230 Vac
max. 50W
Close
Common
Open
Close
Common
Open
Cap Cap
TX
1 2
RX
1 2 3 4 5
Common
Sensitive edge
Internal photocell (N.C)
External photocell (N.C.)
Common
O/C
Ped
Stop
E.L.
12V 15W
2nd radio
channel
Gate open
warning light
max. 3W
Ext.
photoc.
Int.
photoc.
RX
1 2 3 4 5
TX
1 2
Antenna
