SECTION 1 PAGE 3
MB-T48-01
Standard Specifications
ITEM SPECIFICATION
Occupancy 2 Passenger
Dimension Taylor Truck 318L X 127W X 119H Centimeters
125L X 50W X 47H Inches
ET 3000 325L X 127W X 191H Centimeters
128L X 50W X 75H Inches
Turning Radius 368 Centimeters
145 Inches
Dry Weight Taylor Truck 696 kg
1534 lbs
ET 3000 856 kg
1884 lbs
Maximum Load 1360 kg
3000 lbs
Electrical System 8-244 Amp HR., 6 Volt, Lead Acid Batteries
System Voltage 48 Volts
Controller Solid State, 500 Amp, 48 Volts
Transmission Helical Gear, Oil Bath,
Automotive Type Hypoid Differential.
Motor DC Separately Excited Field,
48V, 5.9kW, for 60 min
Speed (Unloaded) 18 mph
Brakes 4 Wheel Hydraulic Disc,
Park Brake, Hand Operated
Steering Automotive Steering 24:1
Tires 20.5 X 8 X 10 Load Range, E
Tire Pressure 90 psi max
Frame Steel Unitized Body
Heavy Duty 14 Gauge Smooth Skin Steel
Instrumentation Battery Discharge Indicator, Key Switch
Forward/Reverse Switch, Headlight Switch,
Hour Meter
Light Accessories Dual Headlights, Dual Tail/Brake Lights
ET 3000 Directional Turn Signals
Charger 115v AC, 15A 60Hz, 25 Amp DC, 48 Volt
Built-In Automatic
