OPERATOR PARTS IDENTIFICATION
4-9
Model 0736
Operator Parts Identification
4
Tune Up Kit
Figure 4-8
Item Description Part No.
1 Kit-Tune Up *0736* 087774
2 O-ring-DEL Tube/Regulator 087762
3 O-ring-Pump 087759
4 O-ring-Baffle 087730
5 O-ring-Draw-Valve 087743
6 Valve-Check-Duckbill-Pump 087742
7 Valve-Pump 087765
8 Seal-Beater-Drive-Shaft 087734
Item Description Part No.
9 Bearing-Door-Baffle 087731
10 Cap-Agitator 087875
11 O-ring-Handle-Pin 087749
12 O-ring-Handle-Body 087753
13 O-ring-Door-Small 087745
14 O-ring-Pump-Body 087755
15 O-ring-Door-Large 087744
16 Tool-O-ring Removal-Freezer 048260-F
