Taylor 150 Service Manual

2
Introduction
Models 150, 152, 162, 168
040309
Safety
_________________________________
We at Taylor Company, are committed to
manufacturing safe operating and serviceable
equipment. The many built-in safety features that are
part of all Taylor equipment are aimed at protecting
operators and trained service technicians alike.
This manual is intended exclusively for Taylor
Company authorized service personnel.
Stationary appliances which are not equipped
with a power cord and a plug or other device to
disconnect the appliance from the power source must
have an all--pole disconnecting device with a contact
gap of at least 3 mm installed in the external
installation. Failure to follow this instruction may result
in electrocution.
These machines must be placed on a level
surface. Failure to comply may result in personal injury
or equipment damage.
DO NOT install the unit in an area where a
water jet could be used to clean or rinse the freezer .
Failure to follow this instruction may result in serious
electrical shock.
These machines are designed to operate indoors,
under normal ambient temperatures of 70_-- 7 5_F
(21_-- 2 4 _C). The machines have successfully
performed in high ambient temperatures of 104_F
(40_C) at reduced capacities.
NOISE LEVEL: Airborne noise emission does not
exceed 78 dB(A) when measured at a distance of 1.0
meter from the surface of the machine and at a height
of 1.6 meters from the floor.
Refrigerant
_________________________________
Taylor Company uses R404A refrigerant. This
refrigerant is generally considered non-toxic and
non-flammable; however, any gas under pressure is
potentially hazardous.
NEVER fill any refrigerant cylinder
completely with liquid. Filling the cylinder to
approximately 80% will allow for normal expansion.
Refrigerant liquid sprayed onto the skin may
cause serious damage to tissue. Keep eyes and skin
protected. If refrigerant burns should occur, flush
immediately with cold water. If burns are severe,
apply ice packs and contact a physician
immediately.
The Taylor Company reminds technicians to be
cautious of government laws regarding
refrigerant recovery, recycling, and reclaiming
systems. If you have any questions regarding
these laws, please contact the factory Service
Department.
WARNING: R404A refrigerant used in conjunction
with polyolester oils is extremely moisture
absorbent. When opening a refrigeration system, the
maximum time the system is open must not exceed
15 minutes. Cap all open tubing to prevent humid air
or water from being absorbed by the oil.

Taylor 150 Specifications

General

Brand	Taylor
Model	150
Category	Freezer
Language	English
