Taylor 336 User Manual

9
Models 336, 338 & 339 Operator Parts Identification
111101
Model 339
Figure 3
Item Description Part No.
1 Cover A.--Hopper--Standard X38458 --SER
2 Gasket--Hopper Cover 20 Qt. 038474
3 Orifice 022465--100
4 O--Ring 3/8 OD x .070 W 016137
5 Tube A.--Feed SS 5/32 Hole X29429--2
6 O--Ring .643 OD x . 077 W 018572
7 Panel--Rear 053782
8 Louver--Side Top 051191
9 Panel--Upper Side Right 028741
10 Panel A.--Lower Side (R & L) X24424
Item Description Part No.
11 Pan--Drip 17 --1/4” Long 027504
12 Panel--Upper Side Left 028740
13 Stud --Nose Cone 022822
14 Panel A.--Front X32956
15 Adaptor A. --Caster X18915
16 Caster--Swivel 5/8 Stem 4” 018794
17 Caster--4” Swv 5/8 Stem w/Brake 034081
18 Panel--Service 024439
19 Shield--Splash 23 L 022766
20 Tray--Drip 22--7/8 L x 5--1/8 W 014533

Taylor 336 Specifications

General

Brand	Taylor
Model	336
Category	Ice Cream Maker
Language	English
