Models 336, 338 & 339Operator Parts Identification
Three Spout Door
Figure 4
Item Description Part No.
1 Seal--Drive Shaft 032560
2 Shaft--Beater 033235
3 Beater A.--2.8 Qt. Helicore X35466
4 Blade--Scraper--Plastic 035480
5 Bearing --Front 050216
6 Gasket--Door HT 4” Double 048926
7 O--Ring 3/8 OD x .070 W 016137
8 Plug--Prime 028805
9 Handle A.--Draw--Adjustable X55096
9a Handle--Adjustable 028804
9b Screw--Adjustment--Stainless 055092
Item Description Part No.
9c O--Ring 1/4 OD x .070 W 015872
9d Nut--5/16--24 18--8 SS Jam 029639--BLK
10 Nut--Stud Long 034382
11 Nut--Stud Short 034383
12 Valve A.-- Draw X18303
13 O--Ring 7/8 OD x .103 W 014402
14 Cap--Design 1.010” ID --6 Point 014218
15 O--Ring5/16ODx.070W 016272
16 Rod A.--Pivot X20683
17 Door A.--3 Spout X51532--15
