38
Parts
Models 340/341/342
Control A. X49284 -- Models 341 & 342
ITEM DESCRIPTION PART NO.
1 BOX-CONTROL 049041
2 RELAY-3 POLE-20A-208/240 012725-
3 CONTROL-MIX LEVEL 031799-
4 SCREW-8X1/4 SL HEX HD TYP B 009894
5 LUG-GROUNDING 260 020928
6 SCREW-10-32X1/2 MF HEX CAP 020982
ITEM DESCRIPTION PART NO.
7 NUT-10-32 MF LOCK 020983
8 LABEL-GROUNDING SYMBOL 017669
9 LABEL-COPPER COND ONLY 025948
10 SCREW-8 X 1-1/4 RD HD TYP B 039420
11 BLOCK-TERMINAL 2P-L1,L2
(230 VOLT)
039422
