Taylor 390 Operating Instructions

Section 10 Parts List
17
+ Available Separately
Model 390 Parts List
Copeland Compressor - J8086700/Up (Update 134)
DESCRIPTION PART
NUMBER
QTY. WARR.
CLASS
REMARKS
PARTS
UPDATE
ARM-BAFFLE *390* 047729 1 103 J4040000/UP 83 BAFFLE ASSEMBLY X47731 1 103 J4040000/UP 83
+O-RING-.291 ID X .080W 018550 1 000
BEARING-FRONT 013116 1 000 BEARING-GUIDE 014496 1 000 J4040000/UP 83 BEARING-REAR SHELL *PLASTIC* 032511 1 000
+ WASHER-BEARING LOCK 012864 1 000 + O-RING-1 -1/16 OD X .070 WALL 018432 1 000 + NUT-BRASS BEARING 028991 1 000 + GUIDE -DRIP SEAL 028992 1 000
BEARING-UNIT-REAR 1 PULLEY 1 103 SEE KIT A.-REAR BEARING UNIT 129 BEATER A. -7QT-1 PIN-SUPPORT X46233 1 103
+ BLADE-SCRAPER-PLASTIC 9-13/16L 046237 2 000 + CLIP -SCRAPER BLADE 046238 2 103
PIN-SCRAPER BLADE 009839 2 000
BELT-POLY V-525J10 047728 1 000 J4040000/UP 83 BLOCK-TERMINAL 2P 039422 1 103 BRUSH-DOUBLE ENDED -PUMP&FEED T 013072 1 000 BRUSH-DRAW VALVE 1”ODX2”X17”L 013073 1 000 BRUSH-MIX PUMP BODY-3”X7”WHITE 023316 1 000 BRUSH-REAR BRG 1IN.DX2IN.LGX14 013071 1 000 COMPRESSOR-RS80C1E-CAV (NEW) 051958 - 1 512 COPELAND - J8086700/UP 134
+ CAPACITOR-RUN 012906 1 103 230 -60-1 + CAPACITOR-START 033044-1 1 103 230 -60-1 + RELAY -START-COMPRESSOR 051957-27 1 103 230 -60-1
COMPRESSOR-M50B103BBCB (OLD) 047065- 1 512 BRISTOL - PRIOR TO J8086700 134
+ CAPACITOR -RUN- 15UF/370V 047070 1 103 230 -60-1
+ CAPACITOR -START-124 -149UF/250V 047069 1 103 230-60 -1 + RELAY-START-COMPRESSOR 047067 1 103 230 -60-1
COMPRESSOR-RS80C1E-TF5-224 (NEW) 051958 -33 1 512 3 PHASE - COPELAND - J8086700/UP 134 COMPRESSOR-L51B562DBLB (OLD) 048343-33 1 512 3 PH. - BRISTOL - PRIOR TO J8086700
