Taylor 390 Operating Instructions

+ Available Separately
18
Parts List Model 390
DESCRIPTION
PARTS
UPDATE
REMARKSWARR.
CLASS
QTY.PART
NUMBER
CONDENSER-AC-15LX14HX2.59T-3RW 046558 1 103 COUPLING A.-TORQUE-SHAKE-HEX X48316 1 103
COUPLING-TORQUE-DRIVE 046866 1 103 COUPLING-TORQUE-LOAD-HEX 039397 1 103 PIN-COUPLING-TORQUE 039453 3 103 SCREW-5/16 -18 X 3/8 ALLEN SET 025376 2 000 SCREW-SHOULDER 3/16D X 1/2L -SS 039455 3 000 SPRING-3/8 ODX3/16 IDXIL-BLUE 039987 3 103
COVER A. -HOPPER-STD X38458 1 103
+ KNOB-MIX COVER 025429 1 103
DECAL -CLEAN INST.-HOPPER 019029 1 000 DECAL -DEC-TAYLOR -380 045452 1 000 DECAL -TROUBLESHOOTING 038374 1 000 DECAL -WASH-OFF-AUTO 014502 1 000 DEFLECTOR-AIR 048549 1 103 SINGLE PHASE & THREE PHASE 135 DIAGRAM-WIRING *390* 047730- 1 000 J4040000/UP 83 DOOR A.-PARTIAL *340-350-450* X39248 1 103
+ BUSTER-ICE *390* 047735 1 103 J4040000/UP 83 + GASKET-DOOR 5.109”ID X 5.630OD 014030 1 000 + HANDLE A.-DRAW-SLUSH -BLACK X47384 1 103 + O-RING-1”OD X .139W 032504 2 000 DRAW VALVE + VALVE A.-HANDLE PIN X25929 1 103 + VALVE-DRAW *390* 047734 1 103 J4040000/UP 83
DRYER-FILTER 3/8 X 1/4 SOLDER (NEW) 048901 1 000 J8086700/UP 134 DRYER-FILTER 3/8 X 1/4 SOLDER (OLD) 045866 1 000 PRIOR TO J8086700 GASKET -HOPPER COVER-20 QT-SGL 038375 1 000 GUIDE A.-DRIP PAN *340*341*390 X47190 1 103 HOOD *390* 021222-SP4 1 103 KIT A.-REAR BEARING UNIT X39162 -SER 1 103 INCLUDES RETAINING PLATE 129 KIT A.-TUNE UP X39969 1 000
BEARING-FRONT 013116 1 000 BEARING-GUIDE 014496 1 000 GASKET -DOOR 5.109”ID X 5.630OD 014030 1 000
