Taylor 390 Operating Instructions

19
+ Available Separately
Model 390 Parts List
020624
DESCRIPTION
PARTS
UPDATE
REMARKSWARR.
CLASS
QTY.PART
NUMBER
O-RING -.291 ID X .080W 018550 1 000 BAFFLE ASSEMBLY O-RING -7/8 OD X .139W 025307 1 000 DRIVE SHAFT O-RING -1”OD X .139W 032504 2 000 DRAW VALVE SEAL -DRIVE SHAFT 032560 1 000 DRIVE SHAFT TOOL -O-RING REMOVAL 048260-WHT 1 000
LABEL -DOOR-WARN -MOVE PARTS 032749 1 000 LABEL -WARN-COVER 051433 5 000 LEG-4” SS-W/ORING 013458 4 103 LIGHT-ADD MIX-AMBER-RECTANGULR 047141- 1 103 LIGHT-MIX OUT-AMBER-RECTANGULAR (NEW) 050036- 1 103 J8086700/UP 135 LIGHT-MIX OUT-RED-RECTANGULAR (OLD) 047142- 1 103 PRIOR TO J 8086700 LINE A.-LIQUID *390* X47012 1 103 CAPILLARY TUBE-HOPPER LUBRICANT-SUPER TAYLOR 047518 1 000 LOUVER-SIDE - LEFT (NEW) 013631 1 103 J8086700/UP (1 LOUVER ONLY - L/S) 134 LOUVER-SIDE (OLD) 013631 2 103 PRIOR TO J8086700 (2 LOUVER -
LEFT/RIGHT SIDE)
134
+ SCREW-10-32X3/8 RHM-ZP 002742 8 000 + NUT-10-32 HEX 005598 8 000
MAN-OPER 390 048693-M 1 000 J5026018/UP 90 MOTOR-1/2 HP 024839- 1 212 BEATER MOTOR-FAN 80W 208/230V 60HZ (NEW) 051744-27 1 212 J8086700/UP 134
+ FAN -5 BLADE 12” PUSH 047279 1 212 J8086700/UP 134 + CAPACITOR-RUN (FAN MOTOR) 051785 1 103 J8086700/UP 134 + BOOT-CAPACITOR 031314 1 000 J8086700/UP 134
MOTOR-FAN 50 WATT (OLD) 029770- 1 103 PRIOR TO J8086700
+ FAN-5 BLADE 12” PUSH 22DEG CCW 049009 1 103 PRIOR TO J8086700 116
NUT-STUD *340-342 -344-350 -450* 029880 4 103 HANDSCREWS PAIL-6 QT. 023348 1 000 PAN-DRIP 19 -1/2 LONG 035034 1 103 PANEL A. -FRONT *390* X47004 1 103 PANEL -SIDE *390*LEFT 047006 1 103
+ SCREW-1/4-20X3/8 RHM-STNLS 011694 3 000 + WASHER-PLASTIC PIVOT 013808 2 000
