4.8 BEVERAGE EQUIPMENT:
4.8.6.3 Iced Cappuccino Machine 16 Issue Date: February 21, 2008
Taylor 390 Last Modified: October 31, 2008
Monthly Maintenance:
1. Check rear shell bearing for signs of wear
(excessive mix leakage in the drip pan) and be
certain it is properly cleaned.
2. Dispose of O-Rings or seals that are worn, torn or fit
too loosely and replace with new ones.
Semi -Annual Maintenance:
1. Tune-up Kits are available and all parts should be installed twice annually
(Before Peak Season - March and End of Season - October).
390 Tune-Up Kit
Part Description Quantity
TDL #78116
Front Bearing 2 1/2" Inside Diameter 1 x
Guide Bearing 13/16" Long 1 x
Gasket -Door 5.109"ID x 5.630OD 1 x
O-Ring .291 ID x .080W 1 x
O-Ring 7/8 OD x .139W 1 x
O-Ring 1"OD x .139W 2 x
Drive Shaft Boot Seal 1 x
Tool - O-Ring Removal 1 x
Scraper Blade 2 x
O-Ring .563 OD x .070W 1 x
Lubricant 1 x
NOTE: In order to maximize performance and efficiency of the unit, all parts
should be replaced three times annually even if they do not appear to be
worn, torn or damaged.
2. Rotate scraper blades to allow both sides of the knife edge to wear evenly.
This will contribute to self-sharpening and help maintain fast efficient freezing.
NOTE: Scraper blades must be replaced semi-annually, but should be
carefully inspected for nicks or other damage after three months if the unit is
used in high volume stores.
3. Carefully inspect the bristles on all cleaning brushes (replace if necessary).
NOTE: All brushes should be replaced on an annual basis.
Please contact TFI Canada Toll Free at 1-800-387-2529 if
you have any questions or concerns relating to this product.
Press #1 for Parts and #2 for Service
