Taylor 702 Service Manual

3DUWV /LVW

 $YDLODEOH 6HSDUDWHO\
0RGHOV  3DUWV /LVW
+3 5HIULJHUDQW  6WDUW   -8S   -8S
'(6&5,37,21
3$57
180%(5

47<

47<

47<
:$55
&/$66
5(0$5.6 3$576
83'$7(
ACCUMULATOR-COPPER 2”DIA 10” 047602 1 103
ADAPTOR A.-CASTER X18915 4 4 103
BEARING-FRONT 013116 1 1 2 000
BEARING-REAR SHELL *NICK.PLATE 031324 1 1 2 000
+GUIDE-DRIP SEAL 028992 1 1 2 000
+NUT-BRASS BEARING 028991 1 1 2 000
+WASHER-BEARING LOCK 012864 1 1 2 000
BEATER A.-4QT-1 PIN-SUPPORT X49490 1 103
+BLADE-SCRAPER-PLASTIC 9-13/16L 046237 1 000
+CLIP-SCRAPER BLADE*8.75 INCH* 046238 1 103
BEATER A.-7QT-1 PIN-SUPPORT X46233 1 2 103
+BLADE-SCRAPER-PLASTIC 9-13/16L 046237 2 4 000
+CLIP-SCRAPER BLADE*8.75 INCH* 046238 2 4 103
BELT-AX45 045311 2 000
BELT-AX38 023873 2 000 208/230-60-1
BELT-AX40 023875 2 000 208/230-60-3
BELT-AX36 022849 4 000 208/230-60-1
BELT-AX38 023873 4 000 208/230-60-3
BLOCK-TERMINAL 2P 039422 1 1 2 103 208/230-60-1
BLOCK-TERMINAL 3P 039423 1 2 103 208/230-60-3
BLOWER A. X47833-27 1 1 103
BOOT-CAPACITOR INSULATING 031314 1 1 000
CAPACITOR-RUN- 10 UF/370V 033047 1 1 103
HOUSING A.-W/WHEEL X30160 1 1 103
MOTOR-BLOWER-208/230V 50/60 HZ 046536-27 1 1 103
BRUSH-DOUBLE ENDED-PUMP&FEED TUBE 013072 1 1 1 000
BRUSH-DRAW VALVE 1-1/2”OD X 3” 014753 1 1 1 000
BRUSH-MIX PUMP BODY-3”X7”WHITE 023316 1 1 1 000
BRUSH-REAR BRG 1IN.DX2IN.LGX14 013071 1 1 1 000
CAP-DESIGN-1.188”ID-6 POINT 013139-6 1 1 2 000
CASTER-SWV 5/8 STEM 4IN WHEEL 018794 4 4 103
COMPRESSOR - COPELAND 051958- 1 512 J9010000/UP 137
+CAPACITOR-RUN-20UF/440V 012906 1 103 208/230-60-1
+CAPACITOR-START-189-227UF/330V 033044-1 1 103 208/230-60-1
