Taylor 702 Service Manual

 $YDLODEOH 6HSDUDWHO\

3DUWV /LVW 0RGHOV 
'(6&5,37,21 3$576
83'$7(
5(0$5.6:$55
&/$66

47<

47<

47<
3$57
180%(5
+RELAY-START-COMPRESSOR 051957-27 1 103 208/230-60-1
+KIT-MOUNTING-COMPRESSOR RS 052196 1 000
COMPRESSOR - BRISTOL 048727- 1 512 PRIOR TO J9010000 137
+CAPACITOR-RUN- 20UF/370V 023606 1 103 208/230-60-1
+CAPACITOR-START-161-193UF/25 031790 1 103 208/230-60-1
+RELAY-START-COMPRESSOR 048765 1 103 208/230-60-1
COMPRESSOR - TECUMSEH 047519- 1 512
+CAPACITOR 220/250 AC 50/60HZ 037251-27 1 103 208/230-60-1
+CAPACITOR-START-135-155UF/33 036408 1 103 208/230-60-1
+RELAY-START-COMPRESSOR 036407 1 103 208/230-60-1
COMPRESSOR - TECUMSEH 048259- 2 512
+CAPACITOR-RUN- 20UF/440V 012906 2 103 208/230-60-1
+CAPACITOR-START-161-193UF/25 031790 2 103 208/230-60-1
+RELAY-START-COMPRESSOR 038145 2 103 208/230-60-1
COMPRESSOR - DANFOSS 047701-27 1 1 1 512 SHR 208/230VOLT
+CAPACITOR-START-60UF-220/275V 047703 1 1 1 103 208/230-60-1
+COVER-TERMINAL-COMPRESSOR 047739 1 1 1 103 208/230-60-1
+RELAY-START-COMPRESSOR-TL3G 047702-27 1 1 1 103 208/230-60-1
CONDENSER-AC-12LX16HX2.5T3ROW 048935 1 103 MAIN
CONDENSER-AC-12LX18HX2.6T-3R 048233 1 103 MAIN
CONDENSER-AC-12LX18HX4ROW 050682 2 103 MAIN
CONDENSER-AC-7X6X1.25-2 ROW 027155 1 1 1 103 SHR
CONTROL-MIX LEVEL 031799-27 1 1 2 103 208/230VOLT
CONTROL-TEMPERATURE 028914 1 1 1 103 SHR
CONTROL-THERMISTOR X46015-SER 1 1 2 103
+KNOB-ALUMINUM 027422 1 1 2 103
COVER A.-HOPPER-STD X38458-SER 1 1 103 INCLUDES KNOB
+KNOB-MIX COVER 025429 1 1 103
+GASKET-HOPPER COVER-20 QT-SGL 038375 1 1 000
COVER A.-HOPPER INS.-PARTIAL X39291-SER 2 103 INCLUDES KNOB
+KNOB-MIX COVER 025429 2 103
DECAL-CLEAN INST.-HOPPER 019029 1 1 1 000
DECAL-DEC-TAYLOR 021872 1 1 1 000
DECAL-STANDBY ON-OFF (OLD) 048493 1 1 2 000 PRIOR TO J8050000 129
DECAL-TROUBLESHOOTING 038374 1 1 1 000
