Taylor 702 Service Manual

 $YDLODEOH 6HSDUDWHO\

3DUWV /LVW 0RGHOV 
'(6&5,37,21 3$576
83'$7(
5(0$5.6:$55
&/$66

47<

47<

47<
3$57
180%(5
+SEAL-DRIVE SHAFT 032560 1 1 2 000
SHELL A.-INSULATED*702*12 INCH X50815 1 512
+STUD-NOSE CONE 022822 4 103
SHELL A.-INSULATED *19 INCH* X49770 1 2 512
+STUD-NOSE CONE 022822 4 8 103
SHIELD-MIX-GEAR REDUCER 3-3/8” 013356 1 1 2 103
SHIELD-SPLASH 037041 1 103
SHIELD-SPLASH 15”L X 5-13/32”W 022763 1 1 103
SKIRT-AIR FLOW 049069 1 103
STARTER-BEATER 041950- 1 1 2 103
29(5/2$'7+(50$/ 047150-     
SWITCH A.-DRAW *632-710-31-41- X51242 1 2 103
ARM A.-DRAW VALVE X28874 1 2 103
BRACKET-DOOR SWITCH 028875 1 2 103
E-RING 3/16 .335 O.D. 049178 1 2 000
PIN-PIVOT 015478 1 2 103
PLATE-DRAW VALVE LIMITER *702* 051241 1 2 103
SPRING-RETURN 015342 1 2 103
SWITCH-LEVER-SPDT-10A-125-250V 028889 2 4 103
SWITCH A.-DRAW *632-710-31-41- X28891-SER 1 103
ARM A.-DRAW VALVE X28874 1 103
BRACKET-DOOR SWITCH 028875 1 103
E-RING 3/16 .335 O.D. 049178 1 000
PIN-PIVOT 015478 1 103
SPRING-RETURN 015342 1 103
SWITCH-LEVER-SPDT-10A-125-250V 028889 2 103
SWITCH-PRESSURE 405 PSI-SOLDER 052663 1 103 J9010000/UP - COPELAND 137
SWITCH-PRESSURE 440 PSI-SOLDER 048230 1 1 2 103 702-PRIOR TO J9010000 137
SWITCH-ROCKER-DPDT ON-OFF-ON 014237 1 1 2 103
+BRACKET-ROCKER SWITCH 020820 1 1 2 103
+CARD-WASH-OFF-AUTO 014091 1 1 2 000
SWITCH-TOGGLE-DPDT*ON-NONE-ON 024295 1 1 2 103 SHR/CTR
TIMER-CYCLE 5SEC ON/120SEC OFF 037188- 1 1 4 103
TRANS.-240V PR1/24V SEC 10 VA 030132- 1 1 2 103
TRAY-DRIP14-7/8LX5-1/8SGL 013690 1 1 103
