Taylor 702 Service Manual


 $YDLODEOH 6HSDUDWHO\
0RGHOV  3DUWV /LVW
'(6&5,37,21 3$576
83'$7(
5(0$5.6:$55
&/$66

47<

47<

47<
3$57
180%(5
TRAY-DRIP22-7/8LX5-1/8W 014533 1 103
TRIM-CORNER *390*LEFT 047002 1 103
TRIM-CORNER *390*RIGHT 047003 1 103
TRIM-FRONT *390* 047001 1 103
TRIM-REAR CORNER 013620 2 103
TRIM-REAR CORNER LEFT 013761 1 103 LEFT
TRIM-REAR CORNER RIGHT 013663 1 103 RIGHT
TUBE-FEED-SS-3/16 028967-3 1 2 103
TUBE-FEED-SS-5/32 HOLE 028967-2 1 103
VALVE-ACCESS 1/4FL X 1/4SOLDER 044404 1 2 1 103
VALVE-ACCESS 1/4FL X 3/8SDR-90 044455 1 2 103
VALVE-ACCESS 1/4FL X 3/8SOLDER 043232 1 103
VALVE-ACCESS-1/4 MFLX1/4 S-90 047016 2 1 3 103
VALVE-EPR 1/4S 022665 1 1 1 103
VALVE-EXP-AUTO-1/4S X1/4 FPT 046365 1 1 2 103
+BOOT-EXPANSION VALVE 050900 1 1 2 000
VARISTOR A.-SLEEVE TERMINAL X31547 1 1 2 103 THERMISTOR CONTROL
VIDEO-TRAIN FILM-DUALMASTER/SH 043568-V 1 1 1 000
WATER COOLED
ACCUMULATOR-COPPER 2”DIA 10”LG 047062 1 2 103
ADAPTOR-3/8MP X 1/2BARB 011021 1 1 103
BLOWER-100 CFM 012796-27 1 1 103 208/230VOLT
CONDENSER-WC-COAX 048287 1 2 103
CONDENSER-WC-SPIRAL 11-1/2 049309 1 103
GUARD-BLOWER 022505 1 1 103
HOSE-RUBBER 1/2”ID X 7/8” R50200 4ft 4ft 13ft 000
MOTOR-FAN-25W 015184-27 1 103 208/230VOLT
+FAN-5 BLADE 10 ” PUSH 013043 1 103
OUTLET A.-TEE X25900 1 103
PANEL A.-SIDE LOWER X24397 2 2 103
SWITCH-PRESSURE 350 PSI 048231 1 1 2 103
VALVE-WATER 3/8 REG/HEAD 046686 1 1 2 103
