16
Models 750, 751, 754, 774, 791, 794Operator Parts Identification
151222
Model 791 Three Spout Door and Beater Assembly
Figure 2
ITEM DESCRIPTION PART NO.
1 HANDLE A. - DRAW *WHITE X81010- SP
1a O- RING 1/4OD X .070W 015872
1b SCREW- ADJUSTMENT 056332
2 PLUG - PRIME 028805
3 ROD A. - PIVOT X20683
4 NUT - STUD *LONG 034382
5 NUT- STUD *SHORT 034383
6 VALVE A.- DRAW X69539
7 O - RING- 7/8 OD X .103W- SIL 083693
8 CAP - DESIGN 014218
9 DECAL- DOOR- 3 SPOUT 021521
ITEM DESCRIPTION PART NO.
10 DOOR A.- 3 SPOUT X51532- 12
10a BAFFLE A.- LONG 4 IN X50882
11 O- RING- PRIME PLUG 016137
12 O- RING 5/16OD X .070W 016272
13 GASKET- DOOR HT 4” 048926
14 BEARING- FRONT 050216
15 BEATER A. - HELICORE X31761
16 BLADE- SCRAPER 035174
17 SHAFT- BEATER 032564
18 SEAL- DRIVE SHAFT 032560
