Taylor C602 Instruction Manual

1
INTRODUCTION
The Model C602 is a combination shake and
soft serve freezer. The soft serve side uses a
3.4 quart (3.2 liter) freezing cylinder with a
single spout door.
The shake side has a 7 quart (6.6 liter)
freezing cylinder with a four flavor dispensing
door. The touch panel has four flavor symbols
for selecting and drawing the desired shake
flavor. When dispensing a shake, the cup is
placed on the shake cup holder located below
the door spout. A shake flavor symbol
is
selected to automatically raise the draw valve,
allowing frozen mix and syrup to enter the
door where they are blended and dispensed
as a finished shake.
A portion control device will sense the filling of
the shake cup and automatically close the
draw valve upon f illing the shake cup to the
correct level. The operator also has the ability
to override the portion control and stop
dispensing the shake by touching any of the
four shake flavor symbols. The shake draw
valve can also be raised and lowered in the
WASH and OFF modes by selecting any of
the four flavor symbols to enable cleaning,
sanitizing, and priming.
Shake syrup is stored in the lower front
compartment. Each syrup flavor is delivered to
the dispensing door by a peristaltic pump.
Syrup can be pumped directly from disposable
plastic jugs, stainless steel tanks, or adapted
to syrup-in-bag dispensing. The proper syrup
delivery rate is achieved by calibrating each
syrup flavor.
The mix is located in the mix hopper and is
pumped to the freezing cylinder by an air/mix
pump.
When your machine is delivered or if it has
been in the OFF position for more than 24
hours, disassemble the freezer following the
Manual Brush Cleaning procedures found on
page 54. Follow the Equipment Set -Up
procedures on page 60 to re -assemble your
machine.
The machine must be disassembled, cleaned,
sanitized and lubricated at least once every
two weeks. Syrup lines must be cleaned and
sanitized weekly.
It is recommended that these operating
procedures be followed closely to insure
correct assembly an d disassembly of the
freezer.
The C602 is designed for indoor use only.
SAFETY
Always follow these safety precautions when
operating the freezer:
DO NOT operate the freezer without
reading this operator’s manual. Failure to
follow this instruction may result in equipment
damage, poor freezer performance, health
hazards, or personal injury.
DO NOT operate the freezer unless it
is properly grounded. Failure to follow this
instruction may result in electrocution.
All repairs must be performed by an
authorized Taylor service agent. The main
power supplies to the freezer must be
disconnected prior to performing any repairs.
Failure to follow this instruction may result in
personal injury, equipment damage, poor
freezer performance, or health hazards.
Stationary appliances which are not
equipped with a power cord and a plug or
other device to disconnect the appliance from
the power source must have an all-pole
disconnecting device with a contact gap of at
least 3 mm installed in the external installation.
Failure to follow this instruction may result in
electrocution.
DO NOT operate the freezer with
larger fuses than specified on the freezer data
label. Failure to follow this instruction may
result in electrocution or damage to the
machine. Consult your electrician.
