Taylor C706 Original Operating Instructions

8
Model C706Operator Parts Identification
110509
Model C706 Single Spout Door and Beater Assembly
ITEM DESCRIPTION PART NO.
1 DOOR A. --W/BAFFLE X56071 --SER
2 HANDLE A.-DRAW-WELDED X56246
3 SCREW-ADJUSTMENT-5/16-24 056332
4 O-RING-1/4 OD X .070W 50 015872
5 PIN--HANDLE--S.S. 055819
6 PLUG -- PRIME 028805
7 O--RING -- 3/8 OD X .070W 016137
8 VALVE A . -- DRAW X56072
9 O--RING -- 7/8 OD X .103 W 014402
ITEM DESCRIPTION PART NO.
10 NUT--STUD BLACK --3.25 LONG 058765
11 NUT--STUD BLACK --2.56 LONG 058764
12 GASKET--DOOR HT 4” DBL 048926
13 KIT A.--BEATER FRONT SHOE X50350
14 BEATER A. -- 3.4 QT. -- 1 PIN X46231
15 CLIP -- SCRAPER BLADE -- 7” 046236
16 BLADE--SCRAPER--PLASTIC 046235
17 SHAFT -- BEATER 056078
18 SEAL -- DRIVE SHAFT 032560

Taylor C706 Specifications

General

Model	C706
Category	Freezer
Refrigeration System	Air Cooled
Air Cooled	Yes
Water Cooled	No
Weight	220 lbs
