Taylor C706 Original Operating Instructions

22
Model C706Operating Procedures
041118
Step 4
Install the pump assembly. To position the pump on the
drive hub at the rear of the mix hopper, align the drive
hole in the piston with the drive crank of the drive shaft.
Secure the pump in place by slipping the pump clip
over the collar of the pump, making sure the clip fits
into the grooves in the collar.
Figure 32
Step 5
Place the power switch in the ON position.
Figure 33
Step 6
Press the WASH key. This will cause the sanitizing
solution in the freezing cylinder to agitate. Allow it to
agitate for five minutes.
Figure 34
Step 7
With an empty pail beneath the door spout, raise the
prime plug and press the PUMP key.
Figure 35

Taylor C706 Specifications

General

Model	C706
Category	Freezer
Refrigeration System	Air Cooled
Air Cooled	Yes
Water Cooled	No
Weight	220 lbs
