+ Available Separately
36
Parts List Model C706
DESCRIPTION REMARKSW ARR.
CLASS
QTY.PART
NUMBER
+RELAY--START--COMPRESSOR 036047 1 103
COMPRESSOR L63A1 13DBLA 048259--33 1 512 208--230V 60HZ 3PH, K7026650 -- BRISTOL
COMPRESSOR AHA2490ZXF--AH556RF 047519--33F 1 512 208--230V 60HZ 3PH, K7015617/PRIOR -- TECUMSEH
COMPRESSOR PL35G 055187--27 1 512 SHR
+RELAY--START--COMPRESSOR 055358 1 103
+CAPACITOR--ST AR T 60UF--220/275 047703 1 103
CONDENSER--AC--15LX14HX2.59T--3RW 046558 1 103 MAIN REFRIGERATION
CONDENSER--AC--7X6X1.25--2 ROW 027155 1 103 SHR
COUPLING --DRIVE 3/4 HEX X 1--7/8 012721 1 103
COVER--CONTROL BOX 064111 1
COVER--HOPPER COMPLETE (Black) 053809--1 1 103 K2010000/up USING BLACK COVER U/D 167
+PIN--RETAINING--HOPPER COVER 043934 4 103 U/D 167
DECAL--DEC--TAYLOR C706 057311 1 000
DECAL--INST--CLN--PMP HPR 042170 1 000
DECAL--TROUBLESHOOT 038374 1 000
DIAGRAM--WIRING *C706*C707* 064288--27 1 000 208--230V 60HZ 1PH, K7026650 & UP -- BRISTOL
DIAGRAM--WIRING *C706*C707* 064288--33 1 000 208--230V 60HZ 3PH, K7026650 & UP -- BRISTOL
DIAGRAM--WIRING *C706*C707* 056352--27 1 000 208--230V 60HZ 1PH, K7015617/PRIOR -- TECUMSEH
DIAGRAM--WIRING *C706*C707* 056352--33 1 000 208--230V 60HZ 3PH, K7015617/PRIOR -- TECUMSEH
DOOR A.--W/BAFFLE *C706* X56071--SER 1 103
+HANDLE A.--DRAW--WELDED *C706* X56246 1 103
+SCREW--ADJUSTMENT--5/16--24 *602* 056332 1 103
+O--RING--1/4 OD X .070W 50 DURO 015872 1 000
+GASKET--DOOR HT 4” 048926 1 000
+PIN--HANDLE--SS *C602* 055819 1 103
+PLUG--PRIME 028805 1 103
+O--RING--3/8 OD X .070W 016137 2 000
+VALVE A.--DRAW *C706* X56072 1 103
+O--RING--7/8 OD X .103W 014402 3 000
DRYER--CAP. TUBE .021 ID X 9FT 055522 1 000
DRYER--FILTER--HP62--3/8 X 1/4S 048901 1 000
GASKET--BASE PAN *C 706* 056058 1 000
GEAR A.*REDUCER 4.21:1 021286--SER 1 212
GUARD--FAN 028534--1 1 103 SHR
GUIDEA.--DRIPPAN X28863 1 103 REAR SHELL BEARING -- LONG
