38
Parts List Model C706
DESCRIPTION REMARKSW ARR.
CLASS
QTY.PART
NUMBER
MOTOR A.--FAN 92 WATT 1630 RP 064003--27 1 103 K7026650 & UP -- BRISTOL -- MAIN CONDENSER
+BOOT--CAPACITOR--INSUL 1.75” D 062452 1 000 +CAPACITOR--RUN 2UF 450 VAC 064004 1 103
MOTOR--FAN 80 WATT 1550 RPM CW 051744--27 1 103 208--230V 60HZ 1PH, K7015617/PRIOR -- TECUMSEH
+BOOT--CAPACITOR INSULATING 031314 1 000 +FAN--5 BLADE 12”PUSH 32DEG CCW 047279 1 103 +CAPACITOR--RUN-- 4UF--440V 051785 1 103
MOTOR--FAN 95.3 CFM 2700 RPM * USE X62253--27 KIT -- AUX SYSTEM MOTOR--REDUCER--SERVICE 036955--34S 1 212 MOTO R--REDUCER 32 RPM--HPR PUMP
+CAPACITOR--ST AR T-- 47--56UF/220TO 037251--34 1 103 +RELAY--MTR START TI#4CR--1--625 039725--27 1 103 +OVERLOAD--TI #2BM--20V9R--KK20--71 044464 1 103 +NUT--OVERLOAD RESET 045026 1 000
NUT--STUD--BLACK 2.563 LONG 058764 2 103 K3060000/UP NUT--STUD--BLACK 3.250 LONG 058765 2 103 K3060000/UP ORIFICE 022465--100 1 103
+O--RING--3/8 OD X .070W 016137 1 000
PAIL-- MIX 10 QT . 013163 1 000 PAN A.--DRIP 5 1/2” LONG *C706* X56074 1 103 PAN--DRIP 11--5/8 LONG 027503 1 103 SIDE PANEL PANEL A.--FRONT--UPPER *C706* X58950 1 103 PANEL--FRONT--LOWER *C706* 058942 1 103 PANEL A.--SIDE--RIGHTC706/C707AC X64151 1 103 PANEL--SIDE--LEFT *C706* 056082--SP2 1 103 PANEL--REAR *C706* 056077 1 103 PANEL A.--SIDE--RIGHT *C706* X65441 * 103 TOP AIR DISCHARGE--HI CAP PLUG--DRIP PAN HOLE 029595 1 103 PROBE A.--MIX *SQUARE* X30922 1 103 MIX LOW
+DISC--PROBE *SQ HOLE* 030965 1 103 +SPACER--PROBE *SQ HOLE* 030966 1 103
PROBE A.--MIX OUT--SQUARE HOLE X41348 1 103 MIX OUT
+SPACER --PROBE--ROUND HOLE--5/8DIA 041347 1 103 +SPACER --PROBE--SQUARE HOLE --7/8 041346 1 103
PROBE A.--THERMISTOR X31602 1 103 BARREL PROBE A.--THERMISTOR/RESISTOR X50717 1 103 HOPPER
