Model C712Operator Parts Identification
121022
C712 Exploded View Parts Identification
ITEM DESCRIPTION PART NO.
1 COVER-HOPPER 053809-1
2 PUMP A.-MIX SIMPLIFIED X57029-14
3 PANEL-REAR 064258-SER
4 PAN-DRIP 7.875 059737
5 PANEL-SIDE*RIGHT 059907
6 PAN-DRIP 12.5 059736
7 PANEL A.-FRONT X63879
8 PANEL A.-FRONT X59836
9 STUD-NOSE CONE 055987
10 FILTER-AIR-POLY-FLO 052779-11
11 PANEL A.-FILTER-LOUVERED X59928
12 CASTER-4” SWV 3/4-10 STEM 044106
13 SCREW-1/4-20 X 3/8 RHM 011694
ITEM DESCRIPTION PART NO.
14 PANEL-SIDE-RIGHT 063087
15 DEFLECTOR-BLOWER 047912
16 CASTER-4” SWV 3/4-10 STEM
W/BRAKE
046437
17 PANEL A.-FRONT LOWER X59854-SER
18 SHIELD-SPLASH-WIRE-19-3/4 L 033813
19 TRAY-DRIP-19-5/8 L X 4-7/8 033812
20 PAN-DRIP 19-1/2 LONG 035034
21 PANEL-CORNER-FRONT-LEFT 063088
22 PANEL-SIDE-LEFT 059906
23 FASTENER-DOOR LATCH 030787
24 FASTENER-DOOR STRIKE 030788
