Model C712 Important: To the Operator
130220
Section 5 Important: To the Operator
Figure 6
ITEM DESCRIPTION
1 POWER SWITCH
2 FLUORESCENT DISPLAY
3 KEYPADS
4 MIX OUT INDICATOR
5 STANDBY KEY
6 MIX LOW INDICATOR
ITEM DESCRIPTION
7 SELECT KEY
8 SERVICE MENU KEY
9 BRUSH CLEAN COUNTER
10 ARROW KEYS
11 SYRUP TOPPING HEATER KEY
