Model C712Operating Procedures

Step 6

Before installing the beater assembly, check the

scraper blades for any nicks or signs of wear. If any

nicks are present, or if the blades are worn, replace

both blades.

If the blades are in good condition, install the

scraper blade clips over the scraper blades. Place

the rear scraper blade over the rear holding pin on

the beater. (See Figure 33.)

Figure 33

Note: Scraper blades should be replaced every 3

months.

Note: The hole on the scraper blade must fit

securely over the pin to prevent costly damage.

Step 7

Holding the rear blade on the beater, slide it into the

freezing cylinder halfway. Install the front scraper

blade over the front holding pin. (See Figure 34.)

Figure 34

Step 8

Install the beater shoes. (See Figure 35.)

Figure 35

Step 9

Slide the beater assembly the rest of the way into

the freezing cylinder.

Make sure the beater assembly is in position over

the drive shaft by turning the beater slightly until the

beater is properly seated. When in position, the

beater will not protrude beyond the front of the

freezing cylinder. (See Figure 36.)

Figure 36

Repeat these steps for the other side of the

machine.
