Taylor C712 Operating Instructions

42
Parts List Model C712
DESCRIPTION COMMENTSWARR.
CLASS
QTY.PART
NUMBER
BRUSH-REAR BRG 1"D X 2"LG X 14 013071 1 000 BRUSH-SET LVB 050103 1 000 CABLE-RIBBON-20C-17"L-DIL/DILR 040040-013 1 103 CABLE-RIBBON-50C-25"L.DIL/DIL 040040-025 1 103 CABLE-RIBBON-20C-14"L-DIL/DIL 040040-040 2 103 CABLE-RIBBON-50C-10"L-DIL/DIL 040040-058 1 103 CABLE-USB 056785 1 103 CAP-DESIGN 1.010"ID-6 POINT 014218 3 000 CAP-VALVE BODY SS 056874-12 2 103 CAP-VALVE BODY SS 056874-16 2 103 CASTER-4" SWV 3/4-10 STM 044106 4 103 CLIP-RETAINER-MIX PUMP 044641 2 103 COMPRESSOR TL3G-R134A 047701-27 1 512 AUX
+RELAY-START-COMPRESSOR-TL3G 047702-27 1 103 AUX +CAPACITOR-START 60UF-220/275V 047703 1 103 AUX +KIT-MOUNTING-COMPRESSOR 047704 1 000 AUX
COMPRESSOR CS20K6E-PFV-238 057011-27 2 512 208-230V 60HZ 1PH S/N K7072861
+BLOCK-TERMINAL 2 P L1,L2 039422 2 103 +CAPACITOR-START 189-227UF/33 033044-1 2 103 +CAPACITOR-RUN 40MF/440V 036049 2 103 +RELAY-START-COMPRESSOR 052401-27 2 103
COMPRESSOR CS20K6E-TF5-23 057011-33 2 512 208-230V 60HZ 3PH COMPRESSOR CS20K6E-PFZ-238 057011-40 2 512 220-240V 50HZ 1PH
+BLOCK-TERMINAL 2P L1,N 039421 2 103 +CAPACITOR-RUN 40MF/440V 036049 2 103 +CAPACITOR-START 216-259UF/33 048908 2 103 +RELAY-START-COMPRESSOR 051957-27 2 103
COMPRESSOR CS20K6E-TFD-238 057011-58 2 512 380-415V 50HZ 3N~ (4WIRE)
+BLOCK-TERMINAL 4P L1,L2,L3,N 2 039424 2 103
CONDENSER-AC 7X6X1.25-2 ROW 027155 1 103 AUX CONDENSER-AC 12LX18HX3.12T-5RW 055813-1 1 103 MAIN L EF T CONDENSER-AC 12LX18HX3.12T-5RW 055813-2 1 103 MAIN RIGHT
